C93600 High Leaded Tin Bronze

C936 High Leaded Tin Bronze has the following applications: Industrial: Bushings for corrosion, lubrication or pressure, Cam Bushings for Diesel Engines, Crankshaft Main Bearings, Guide Bushings for Piston Rods, Guide Bushings for Valves, Hydraulic Gland Seals, Locomotive Bearing Parts, Main Bearings for Presses, Piston Pin Bearings, Pump Sleeves, Rod Bushings, Rolling Mill Bearings, Sleeve Bushings (for Cranes, etc.), Bearings for corrosion, lubrication or pressure.

Request a Quote

Temper is required.

Shape/Form is required.

Size or Dimension is required.

Length is required.

Quantity or Lbs is required.

Additional Information or Instructions

Chemical Composition

Applicable Specifications

Fabrication

Thermal

	Cu	Al	Sb	Fe	Pb	Ni⁽¹⁾	P⁽²⁾	Si	S	Sn	Zn
Min./Max.	79.0-83.0	.005	.55	.20	11.0-13.0	1.0	.15	.005	.08	6.0-8.0	1.0
Nominal	81.0	-	-	-	12.0	-	-	-	-	7.0	-

Product	Specification
Centrifugal	ASTM B271
Continuous	ASTM B505
Ingot	ASTM B30
Sand	ASTM B66 MILITARY MIL-C-22229

Joining Technique	Suitability
Soldering	Good
Brazing	Good
Oxyacetylene Welding	Not Recommended
Gas Shielded Arc Welding	Not Recommended
Coated Metal Arc Welding	Not Recommended
Machinability Rating	80

Treatment	Temp./Time - US	Temp./Time - SI
Stress Temperature	500	260
Solution Minimum
Solution Maximum
Solution Time	0.0
Solution Medium	None
Precipitation Value
Precipitation Time
Precipitation Medium	None
Annealing Minimum
